0522713090
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC Connector
PDF
/
Inventory: 4262
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Polyamide (PA46), Nylon 4/6
Actuator Material Polyphenylene Sulfide (PPS)
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series Easy-On 52271
JESD-609 Code e0
Feature Solder Retention, Zero Insertion Force (ZIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Solder
ECCN Code EAR99
Number of Positions 30
Number of Rows 1
Voltage - Rated 50V
HTS Code 8536.69.40.51
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 0.5A per Contact
Pitch 0.039 1.00mm
Total Number of Contacts 30
Reach Compliance Code compliant
Contact Finish Tin-Lead
Contact Gender FEMALE
UL Flammability Code 94V-0
Flat Flex Type FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Tapered
Locking Feature Slide Lock
Dimensions
Contact Finish Thickness 39.4μin 1.00μm
Height Above Board 0.118 3.00mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
