0522712779
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Conn FPC Connector SKT 27 POS 1mm Solder RA SMD Easy-On? T/R
PDF
/
Inventory: 6731
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Contact Material Phosphor Bronze
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Material Nylon
Housing Material Polyamide (PA46), Nylon 4/6
Actuator Material Polyphenylene Sulfide (PPS)
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 52271
Feature Solder Retention, Zero Insertion Force (ZIF)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 27
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Number of Rows 1
Voltage - Rated 50V
Current Rating (Amps) 0.5A
Pitch 0.039 1.00mm
Orientation Right Angle
Depth 6.7mm
Current Rating 500mA
Contact Finish Tin Bismuth
Number of Contacts 27
Housing Color Natural
Number of Circuits 27
Max Voltage Rating (AC) 50V
Max Voltage Rating (DC) 50V
Mating Cycles 30
Flat Flex Type FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Tapered
Locking Feature Slide Lock
Dimensions
Contact Finish Thickness 39.4μin 1.00μm
Height Above Board 0.118 3.00mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
