0522072490
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC Connector
PDF
/
Inventory: 3772
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Polyamide (PA46), Nylon 4/6
Actuator Material Polyphenylene Sulfide (PPS)
Technical
Operating Temperature -20°C~85°C
Packaging Cut Tape (CT)
Series Easy-On 52207
Feature Solder Retention, Zero Insertion Force (ZIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 24
Voltage - Rated 125V
Current Rating (Amps) 1A
Pitch 0.039 1.00mm
Contact Finish Tin-Lead
Mating Cycles 10
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Top
Cable End Type Tapered
Locking Feature Slide Lock
Dimensions
Height Above Board 0.106 2.70mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
