0522072385
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 52207 ROHS3Compliant COMMERCIAL UL CSA FFC, FPC (Connector/Contact Type) Connector ZIF N 20mOhm -30C~85C 1A
PDF
/
Inventory: 6581
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Option 1 LOCKING
Actuator Material Polyphenylene Sulfide (PPS)
Board Mounting Option FITTING NAIL
Technical
Operating Temperature -30°C~85°C
Packaging Cut Tape (CT)
Series Easy-On 52207
JESD-609 Code e6
Feature Solder Retention, Zero Insertion Force (ZIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type FFC/FPC CONNECTOR
Number of Positions 23
Number of Rows 1
Voltage - Rated 125V
HTS Code 8536.69.40.51
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 1A
Pitch 0.039 1.00mm
Total Number of Contacts 23
Reference Standard UL, CSA
Contact Finish Tin Bismuth
Reliability COMMERCIAL
Body Length or Diameter 1.154 inch
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Body Breadth 0.106 inch
Contact Gender FEMALE
UL Flammability Code 94V-0
Body Depth 0.299 inch
Contact Style BELLOWED TYPE
Contact Resistance 20mOhm
Insulation Resistance 100000000Ohm
Dielectric Withstanding Voltage 700VAC V
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min ZIF N
Mating Cycles 30
Insulator Color NATURAL
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Top
Cable End Type Tapered
Locking Feature Slide Lock
Dimensions
Contact Finish Thickness 39.4μin 1.00μm
Plating Thickness 39μin
Height Above Board 0.106 2.70mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
