0522070385
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Conn FPC Connector SKT 3 POS 1mm Solder RA SMD Easy-On? Embossed T/R
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6864
≥1 USD $0.6864
Inventory: 6842
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.106 2.70mm
Contact Finish Thickness 39.4μin 1.00μm
Technical
Locking Feature Slide Lock
Cable End Type Tapered
Connector/Contact Type Contacts, Top
Flat Flex Type FFC, FPC
Insulator Color NATURAL
Mating Cycles 30
Withdrawl Force-Min ZIF N
Insertion Force-Max ZIF N
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 700VAC V
Insulation Resistance 100000000Ohm
Contact Resistance 20mOhm
Contact Style BELLOWED TYPE
Body Depth 0.299 inch
UL Flammability Code 94V-0
Contact Gender FEMALE
Body Breadth 0.106 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Reliability COMMERCIAL
Contact Finish Tin Bismuth
Reference Standard UL, CSA
Total Number of Contacts 3
Pitch 0.039 1.00mm
Current Rating (Amps) 1A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Voltage - Rated 125V
Number of Rows 1
Number of Positions 3
Connector Type FFC/FPC CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Solder Retention, Zero Insertion Force (ZIF)
JESD-609 Code e6
Series Easy-On 52207
Packaging Tape & Reel (TR)
Operating Temperature -30°C~85°C
Physical
Board Mounting Option FITTING NAIL
Actuator Material Polyphenylene Sulfide (PPS)
Mounting Option 1 LOCKING
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
