0520892719
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
52089 ROHS3Compliant GENERAL PURPOSE Slide Lock FPC (Connector/Contact Type) Connector -40C~85C 0.5A 50V 0.30mm
PDF
/
Inventory: 5707
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole, Right Angle
Housing Material Polyamide (PA66), Nylon 6/6
Actuator Material Polyester
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series 52089
JESD-609 Code e6
Feature Zero Insertion Force (ZIF)
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Kinked Pin
Number of Positions 27
Number of Rows 1
Voltage - Rated 50V
Additional Feature LOW PROFILE
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 0.5A
Pitch 0.039 1.00mm
Total Number of Contacts 27
Contact Finish Tin Bismuth
Contact Gender FEMALE
Body/Shell Style RECEPTACLE
Mating Cycles 20
Flat Flex Type FPC
Connector/Contact Type Contacts, Top
Cable End Type Tapered
Locking Feature Slide Lock
Dimensions
Height Above Board 0.118 3.00mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
