0520891210

Molex
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description FFC Connector
PDF
/
Inventory: 2375
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

FFC, FCB Thickness 0.30mm
Height Above Board 0.118 3.00mm

Technical

Locking Feature Slide Lock
Cable End Type Tapered
Connector/Contact Type Contacts, Top
Flat Flex Type FPC
Contact Finish Tin
Pitch 0.039 1.00mm
Voltage - Rated 50V
Number of Positions 12
Termination Kinked Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Zero Insertion Force (ZIF)
Series 52089
Packaging Tray
Operating Temperature -20°C~80°C

Physical

Actuator Material Polyester
Housing Material Polyamide (PA66), Nylon 6/6
Mounting Type Through Hole, Right Angle
Contact Material Phosphor Bronze
