0520890519

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description LOW PROFILE FFC Connector
PDF
/
Inventory: 5458
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Flat Flex Type FPC
Connector/Contact Type Contacts, Top
Cable End Type Tapered
Locking Feature Slide Lock
Mating Cycles 20
Body/Shell Style RECEPTACLE
Contact Gender FEMALE
Contact Finish Tin Bismuth
Total Number of Contacts 5
Pitch 0.039 1.00mm
Current Rating (Amps) 0.5A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature LOW PROFILE
Voltage - Rated 50V
Number of Rows 1
Number of Positions 5
ECCN Code EAR99
Termination Kinked Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Zero Insertion Force (ZIF)
JESD-609 Code e6
Series 52089
Packaging Tray
Operating Temperature -40°C~85°C

Dimensions

Height Above Board 0.118 3.00mm
FFC, FCB Thickness 0.30mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant

Physical

Actuator Material Polyester
Housing Material Polyamide (PA66), Nylon 6/6
Mounting Type Through Hole, Right Angle
Contact Material Phosphor Bronze
