0520302829

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description 52030 ROHS3Compliant GENERAL PURPOSE Slide Lock FPC (Connector/Contact Type) Connector -20C~80C 1A 50V 0.30mm
PDF
/
Inventory: 5633
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Phosphor Bronze
Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Actuator Material Polyester

Technical

Operating Temperature -20°C~80°C
Packaging Tray
Series 52030
JESD-609 Code e6
Feature Zero Insertion Force (ZIF)
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Kinked Pin
ECCN Code EAR99
Number of Positions 28
Number of Rows 1
Voltage - Rated 50V
HTS Code 8536.69.40.51
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 1A
Pitch 0.039 1.00mm
Total Number of Contacts 28
Contact Finish Tin Bismuth
Contact Gender FEMALE
Body/Shell Style RECEPTACLE
Flat Flex Type FPC
Connector/Contact Type Contacts, Vertical - 1 Sided
Cable End Type Tapered
Locking Feature Slide Lock

Dimensions

Height Above Board 0.205 5.20mm
FFC, FCB Thickness 0.30mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
