0520301729
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Conn FFC/FPC Connector SKT 17 POS 2mm Solder ST Thru-Hole Tray
PDF
/
Inventory: 7431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Actuator Material Polyester
Technical
Operating Temperature -20°C~80°C
Packaging Tray
Series 52030
JESD-609 Code e6
Feature Zero Insertion Force (ZIF)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Kinked Pin
ECCN Code EAR99
Number of Positions 17
Number of Rows 1
Voltage - Rated 50V
HTS Code 8536.69.40.51
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 1A
Pitch 0.039 1.00mm
Total Number of Contacts 17
Contact Finish Tin Bismuth
Contact Gender FEMALE
Body/Shell Style RECEPTACLE
Flat Flex Type FPC
Connector/Contact Type Contacts, Vertical - 1 Sided
Cable End Type Tapered
Locking Feature Slide Lock
Dimensions
Height Above Board 0.205 5.20mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
