0514412472
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Conn FPC Connector SKT 24 POS 0.5mm Solder RA SMD Easy-On? T/R
PDF
/
Buying Options
Total Price: USD $18.29
Unit Price: USD $18.293648
≥1 USD $18.293648
≥10 USD $17.258154
≥100 USD $16.281276
≥500 USD $15.359701
≥1000 USD $14.490277
Inventory: 3666
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Technical
Operating Temperature -20°C~85°C
Packaging Tape & Reel (TR)
Series Easy-On 51441
JESD-609 Code e4
Feature Solder Retention, Zero Insertion Force (ZIF)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type FFC/FPC CONNECTOR
Number of Positions 24
Number of Rows 1
Voltage - Rated 50V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 0.5A
Pitch 0.020 0.50mm
Total Number of Contacts 24
Contact Finish Gold
Contact Gender FEMALE
Housing Color Beige
Mating Cycles 20
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Straight, Tapered
Locking Feature Flip Lock
Actuator Color Black
Dimensions
Height Above Board 0.044 1.12mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
