0513742673
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 51374 ROHS3Compliant Flip Lock Solder Retention Zero Insertion Force (ZIF) FFC, FPC (Connector/Contact Type) Connector -25C~85C 0.4A 50V 0.30mm
PDF
/
Inventory: 6985
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mounting Type Surface Mount
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Technical
Operating Temperature -25°C~85°C
Packaging Tape & Reel (TR)
Series Easy-On 51374
Feature Solder Retention, Zero Insertion Force (ZIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 26
Voltage - Rated 50V
Current Rating (Amps) 0.4A
Pitch 0.020 0.50mm
Contact Finish Tin Bismuth
Housing Color White
Mating Cycles 20
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Vertical - 1 Sided
Cable End Type Straight, Tapered
Locking Feature Flip Lock
Actuator Color Brown
Dimensions
Height Above Board 0.159 4.04mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
