0039532314

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description FFC Connector
PDF
/
Inventory: 5078
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 25 Weeks

Physical

Contact Material Phosphor Bronze
Mounting Type Through Hole, Right Angle
Housing Material Polybutylene Terephthalate (PBT), Polyester
Actuator Material Polybutylene Terephthalate (PBT), Polyester

Technical

Operating Temperature -20°C~80°C
Packaging Tray
Series 5597
Feature Zero Insertion Force (ZIF)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 31
Voltage - Rated 200V
Current Rating (Amps) 1A
Pitch 0.049 1.25mm
Contact Finish Tin Bismuth
Mating Cycles 30
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Top
Cable End Type Straight
Locking Feature Slide Lock

Dimensions

Contact Finish Thickness 39.4μin 1.00μm
Height Above Board 0.213 5.40mm
FFC, FCB Thickness 0.30mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
