0039513263
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
5597 ROHS3Compliant Slide Lock Zero Insertion Force (ZIF) FFC, FPC (Connector/Contact Type) Connector -20C~80C 1A 200V 118.1muin 3.00mum
PDF
/
Inventory: 6870
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.213 5.40mm
Contact Finish Thickness 118.1μin 3.00μm
Technical
Locking Feature Slide Lock
Cable End Type Straight
Connector/Contact Type Contacts, Top
Flat Flex Type FFC, FPC
Contact Finish Tin-Lead
Pitch 0.049 1.25mm
Current Rating (Amps) 1A
Voltage - Rated 200V
Number of Positions 26
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Zero Insertion Force (ZIF)
Series 5597
Packaging Tray
Operating Temperature -20°C~80°C
Physical
Actuator Material Polybutylene Terephthalate (PBT), Polyester
Housing Material Polybutylene Terephthalate (PBT), Polyester
Mounting Type Through Hole, Right Angle
Contact Material Phosphor Bronze
