0039513093
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
5597 ROHS3Compliant Slide Lock Zero Insertion Force (ZIF) FFC, FPC (Connector/Contact Type) Connector -20C~80C 1A 200V 118.1muin 3.00mum
PDF
/
Inventory: 2161
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole, Right Angle
Housing Material Polybutylene Terephthalate (PBT), Polyester
Actuator Material Polybutylene Terephthalate (PBT), Polyester
Technical
Operating Temperature -20°C~80°C
Packaging Tray
Series 5597
Feature Zero Insertion Force (ZIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 9
Voltage - Rated 200V
Current Rating (Amps) 1A
Pitch 0.049 1.25mm
Contact Finish Tin-Lead
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Top
Cable End Type Straight
Locking Feature Slide Lock
Dimensions
Contact Finish Thickness 118.1μin 3.00μm
Height Above Board 0.213 5.40mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
