0022153053
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
5229 ROHS3Compliant GENERAL PURPOSE Low Insertion Force (LIF) FFC (Connector/Contact Type) Connector -40C~105C 1A 200V 0.30mm
PDF
/
Inventory: 1974
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole, Right Angle
Housing Material Polyester
Technical
Operating Temperature -40°C~105°C
Packaging Tray
Series 5229
Feature Low Insertion Force (LIF)
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 5
Number of Rows 1
Voltage - Rated 200V
Additional Feature LOW PROFILE
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 1A
Pitch 0.100 2.54mm
Total Number of Contacts 5
Contact Finish Tin
Contact Gender FEMALE
UL Flammability Code 94V-0
Body/Shell Style RECEPTACLE
Flat Flex Type FFC
Connector/Contact Type Contacts, Bottom
Cable End Type Straight
Dimensions
Height Above Board 0.260 6.60mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
