0022023243
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Conn FFC Connector RCP 24 POS 2.54mm Solder ST Thru-Hole Tray
PDF
/
Inventory: 5363
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.256 6.50mm
Technical
Cable End Type Straight
Connector/Contact Type Contacts, Vertical - 1 Sided
Flat Flex Type FFC
Body/Shell Style RECEPTACLE
UL Flammability Code 94V-0
Contact Gender FEMALE
Contact Finish Tin
Total Number of Contacts 24
Pitch 0.100 2.54mm
Current Rating (Amps) 1A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature LOW PROFILE
Voltage - Rated 200V
Number of Rows 1
Number of Positions 24
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Low Insertion Force (LIF)
Series 5229
Packaging Tray
Operating Temperature -40°C~105°C
Physical
Housing Material Polyester
Mounting Type Through Hole
Contact Material Phosphor Bronze
