0022023033

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description 5229 ROHS3Compliant GENERAL PURPOSE Low Insertion Force (LIF) FFC (Connector/Contact Type) Connector -40C~105C 1A 200V 0.30mm
PDF
/
Inventory: 5701
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Current Rating (Amps) 1A
Pitch 0.100 2.54mm
Total Number of Contacts 3
Contact Finish Tin
Contact Gender FEMALE
UL Flammability Code 94V-0
Body/Shell Style RECEPTACLE
Flat Flex Type FFC
Connector/Contact Type Contacts, Vertical - 1 Sided
Cable End Type Straight
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature LOW PROFILE
Voltage - Rated 200V
Number of Rows 1
Number of Positions 3
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Low Insertion Force (LIF)
Series 5229
Packaging Tray
Operating Temperature -40°C~105°C

Physical

Housing Material Polyester
Mounting Type Through Hole
Contact Material Phosphor Bronze

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

FFC, FCB Thickness 0.30mm
Height Above Board 0.256 6.50mm
