0015474180
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
STACKED FFC Connector
PDF
/
Inventory: 9352
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Free Hanging (In-Line)
Housing Material Polyester, Glass Filled
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Series SL 70430
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type FFC/FPC CONNECTOR
Number of Positions 18
Number of Rows 1
Voltage - Rated 250V
Additional Feature STACKED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 18
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color Black
Mating Cycles 50
Flat Flex Type CIC, FFC
Connector/Contact Type Receptacle
Cable End Type Straight
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
FFC, FCB Thickness 0.13 ~ 0.28mm 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
