0015474162
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
SL 70430 ROHS3Compliant GENERAL PURPOSE MULTIPLE MATING PARTS AVAILABLE CIC, FFC (Connector/Contact Type) Connector -40C~105C 250V 15.0muin 0.38mum
PDF
/
Inventory: 2870
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.13 ~ 0.28mm 0.30mm
Contact Finish Thickness 15.0μin 0.38μm
Technical
Cable End Type Straight
Connector/Contact Type Receptacle
Flat Flex Type CIC, FFC
Mating Cycles 50
Housing Color Black
UL Flammability Code 94V-0
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Total Number of Contacts 16
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature STACKED
Voltage - Rated 250V
Number of Rows 1
Number of Positions 16
Connector Type FFC/FPC CONNECTOR
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SL 70430
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Housing Material Polyester, Glass Filled
Mounting Type Free Hanging (In-Line)
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 6 Weeks
