0015474076
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
SL 70430 ROHS3Compliant GENERAL PURPOSE MULTIPLE MATING PARTS AVAILABLE CIC, FFC (Connector/Contact Type) Connector -40C~105C 250V 30.0muin 0.76mum
PDF
/
Inventory: 2503
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.13 ~ 0.28mm 0.30mm
Contact Finish Thickness 30.0μin 0.76μm
Technical
Cable End Type Straight
Connector/Contact Type Receptacle
Flat Flex Type CIC, FFC
Mating Cycles 50
Housing Color Black
UL Flammability Code 94V-0
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Total Number of Contacts 7
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature STACKED
Voltage - Rated 250V
Number of Rows 1
Number of Positions 7
Connector Type FFC/FPC CONNECTOR
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SL 70430
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Housing Material Polyester, Glass Filled
Mounting Type Free Hanging (In-Line)
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 6 Weeks
