0015474032

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description FFC & FPC Connectors SL FFC/FPC Opt D Fem 15 SAu 3Ckt
PDF
/
Inventory: 4139
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

FFC, FCB Thickness 0.13 ~ 0.28mm 0.30mm
Contact Finish Thickness 15.0μin 0.38μm

Technical

Cable End Type Straight
Connector/Contact Type Receptacle
Flat Flex Type CIC, FFC
Mating Cycles 50
Housing Color Black
UL Flammability Code 94V-0
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Total Number of Contacts 3
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature STACKED
Voltage - Rated 250V
Number of Rows 1
Number of Positions 3
Connector Type FFC/FPC CONNECTOR
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SL 70430
Packaging Tube
Operating Temperature -40°C~105°C

Physical

Housing Material Polyester, Glass Filled
Mounting Type Free Hanging (In-Line)
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 6 Weeks
