FB8S039JA2R2000

JAE Electronics
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description FB8 Rotary Lock Zero Insertion Force (ZIF) Gold FPC (Connector/Contact Type) Connector -40C~85C 0.35A per Contact 50V 0.20mm
PDF
/
Inventory: 8225
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper Alloy
Mounting Type Surface Mount, Right Angle
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Actuator Material Polyamide (PA), Nylon, Glass Filled

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series FB8
Feature Zero Insertion Force (ZIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 39
Voltage - Rated 50V
Current Rating (Amps) 0.35A per Contact
Pitch 0.012 0.30mm
Contact Finish Gold
Housing Color Beige
Mating Cycles 20
Flat Flex Type FPC
Connector/Contact Type Contacts, Top
Cable End Type Tapered
Locking Feature Rotary Lock
Actuator Color Black

Dimensions

Height Above Board 0.047 1.20mm
FFC, FCB Thickness 0.20mm

Compliance

Material Flammability Rating UL94 V-0
