FB8S025JA1
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
CONN FPC TOP 25POS 0.30MM R/A
PDF
/
Inventory: 3261
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Actuator Material Polyamide (PA), Nylon, Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2007
Series FB8
Feature Zero Insertion Force (ZIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 25
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated 50V
Current Rating (Amps) 0.35A per Contact
Pitch 0.012 0.30mm
Current Rating 350mA
Contact Finish Gold
Housing Color Beige
Mating Cycles 20
Flat Flex Type FPC
Connector/Contact Type Contacts, Top
Cable End Type Tapered
Locking Feature Rotary Lock
Actuator Color Black
Dimensions
Height Above Board 0.047 1.20mm
FFC, FCB Thickness 0.20mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
