FB6S021JA1
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FB6 RoHS Compliant 2006 Flip Lock FPC (Connector/Contact Type) Connector UL94V-0 85C 350mA 50V
PDF
/
Inventory: 9545
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.15mm
Height Above Board 0.047 1.20mm
Technical
Contact Location Bottom
Actuator Color Black
Locking Feature Flip Lock
Cable End Type Tapered
Connector/Contact Type Contacts, Bottom
Flat Flex Type FPC
Mating Cycles 20
Housing Color Beige
Contact Finish Gold
Current Rating 350mA
Pitch 0.012 0.30mm
Current Rating (Amps) 0.35A per Contact
Voltage - Rated 50V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 21
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Low Insertion Force (LIF)
Series FB6
Published 2006
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Polyamide (PA), Nylon, Glass Filled
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
