FB3S053C11
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC Connector
PDF
/
Inventory: 2219
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mounting Type Surface Mount, Right Angle
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Actuator Material Polyamide (PA), Nylon, Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series FB3
Feature Low Insertion Force (LIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 53
Voltage - Rated 50V
Current Rating (Amps) 0.35A per Contact
Pitch 0.012 0.30mm
Contact Finish Gold
Housing Color Beige
Mating Cycles 20
Flat Flex Type FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Tapered
Locking Feature Flip Lock
Actuator Color Black
Dimensions
Height Above Board 0.075 1.90mm
FFC, FCB Thickness 0.20mm
Compliance
Material Flammability Rating UL94 V-0
