FB3S051C12R3000
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FB3 RoHS Compliant 2014 Flip Lock FPC (Connector/Contact Type) Connector UL94V-0 85C 350mA 50V
PDF
/
Inventory: 8457
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Number of Pins 51
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Actuator Material Polyamide (PA), Nylon, Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2014
Series FB3
Feature Low Insertion Force (LIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 51
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated 50V
Current Rating (Amps) 0.35A per Contact
Pitch 0.012 0.30mm
Current Rating 350mA
Contact Finish Gold
Flat Flex Type FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Tapered
Locking Feature Flip Lock
Dimensions
Height Above Board 0.075 1.90mm
FFC, FCB Thickness 0.20mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
