FB10S013JA2
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC Connector
PDF
/
Inventory: 959
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
FFC, FCB Thickness 0.20mm
Height Above Board 0.035 0.88mm
Contact Finish Thickness 3.94μin 0.10μm
Technical
Actuator Color Black
Locking Feature Flip Lock
Cable End Type Tabbed or Tapered
Connector/Contact Type Contacts, Bottom
Flat Flex Type FPC
Mating Cycles 20
Housing Color White
Contact Finish Gold
Pitch 0.012 0.30mm
Current Rating (Amps) 0.35A
Voltage - Rated 50V
Number of Positions 13
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Zero Insertion Force (ZIF)
Series FB10
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Actuator Material Plastic
Housing Material Plastic
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
