FA5B040HP1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FA5 RoHS Compliant 2004 Flip Lock FPC (Connector/Contact Type) Connector UL94V-0 -40C~85C 800mA 50V
PDF
/
Buying Options
Total Price: USD $7.68
Unit Price: USD $7.683676
≥1 USD $7.683676
Inventory: 75
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Copper Alloy
Mount Edge
Mounting Type Board Edge, Cutout
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Actuator Material Polyamide (PA), Nylon, Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2004
Series FA5
Feature Solder Retention, Zero Insertion Force (ZIF)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 40
Number of Rows 1
Gender Male
Voltage - Rated 50V
Current Rating (Amps) 0.8A per Contact
Pitch 0.020 0.50mm
Current Rating 800mA
Contact Finish Gold
Lead Pitch 500μm
Housing Color Black
Insulation Resistance 100MOhm
Mating Cycles 20
Flat Flex Type FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Tapered
Locking Feature Flip Lock
Actuator Color White
Contact Location Bottom
Dimensions
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
