PCB-C-05-T-20
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
ROHS3Compliant COMMERCIAL UL CSA STAGGERED (Flat Flex Type) (Connector/Contact Type) Connector LIF N 30mOhm 85C 0.5A
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.1672
≥1 USD $0.1672
≥10 USD $0.1408
≥100 USD $0.125312
≥500 USD $0.116943
≥1000 USD $0.10861
≥3000 USD $0.096078
Inventory: 1044
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Mounting Type BOARD
Insulation Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type FFC/FPC CONNECTOR
Number of Rows 1
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating SN ON CU
Total Number of Contacts 5
Terminal Pitch 2.0066mm
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 0.313 inch
Number Of PCB Rows 2
PCB Contact Pattern STAGGERED
Operating Temperature (Max) 85°C
Body Breadth 0.102 inch
Operating Temperature (Min) -40°C
Body Depth 0.217 inch
Rated Current (Signal) 0.5A
Contact Style BELLOWED TYPE
Contact Resistance 30mOhm
Insulation Resistance 500000000Ohm
Mating Contact Pitch 0.039 inch
Termination Type SOLDER KINKED LEADS
Dielectric Withstanding Voltage 500VAC V
PCB Contact Row Spacing 2.0066 mm
Contact Pattern RECTANGULAR
Insertion Force-Max LIF N
Insulator Color BLACK
Dimensions
Length - Termination 0.118 inch
