B66433G0000X187
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
ER 28/17/11 N87 2400 +30%-20%
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.666181
≥1 USD $0.666181
≥10 USD $0.628476
≥100 USD $0.592901
≥500 USD $0.559334
≥1000 USD $0.527673
Inventory: 1138
Minimum: 1
-
+
Technical Details
Physical
Supplier Device Package ER 28 x 17 x 11
Material N87
Technical
Series B66433
Tolerance -20% +30%
Part Status Not For New Designs
Finish Uncoated
Effective Area (Ae) mm2 85.4
Effective Length (le) mm 75
Effective Magnetic Volume (Ve) mm3 6400
Core Factor (ΣI/A) mm1 0.88
Minimum Core Cross Section (Amin) mm2 77
Dimensions
Height 0.449 11.40mm
Length 1.124 28.55mm
Width 0.665 16.90mm
Compliance
RoHS Status ROHS3 Compliant
