B66421G0500X187
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
FERRITE CORE
PDF
/
Inventory: 5457
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Supplier Device Package EFD 25 x 13 x 9
Material N87
Technical
Published 2013
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type EFD
Effective Area (Ae) mm2 58
Effective Length (le) mm 57
Effective Magnetic Volume (Ve) mm3 3310
Core Factor (ΣI/A) mm1 0.98
Initial Permeability (μi) 2200
Dimensions
Height 12.50mm
Length 25.00mm
Width 9.10mm
Compliance
RoHS Status ROHS3 Compliant
