B66387G3000X127
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
FERRITE CORE
PDF
/
Inventory: 5653
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Supplier Device Package E 65 x 32 x 27
Material N27
Technical
Published 2013
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type E
Effective Area (Ae) mm2 535
Effective Length (le) mm 147
Effective Magnetic Volume (Ve) mm3 78600
Core Factor (ΣI/A) mm1 0.27
Initial Permeability (μi) 2000
Minimum Core Cross Section (Amin) mm2 529
Dimensions
Height 32.80mm
Length 65.00mm
Width 27.40mm
Compliance
RoHS Status ROHS3 Compliant
