B65981A0000R097
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
EPCOS B65981A0000R097Transformer Cores, PQ, PQ50/50, N97, 113 mm, 330 mm
PDF
/
Buying Options
Total Price: USD $15.09
Unit Price: USD $15.092
≥1 USD $15.092
≥10 USD $13.5828
≥100 USD $10.262507
≥500 USD $9.9605
≥1000 USD $8.753228
≥3000 USD $8.384306
Inventory: 427
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Supplier Device Package PQ 50 x 50
Material N97
Technical
Published 2009
Series B65981A
Tolerance -20% +30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type PQ
Gap Ungapped
Effective Area (Ae) mm2 330
Effective Length (le) mm 113
Effective Magnetic Volume (Ve) mm3 37270
Core Factor (ΣI/A) mm1 0.342
Minimum Core Cross Section (Amin) mm2 290
Inductance Factor (Al) 6.7μH
Effective Permeability (μe) 1825
Dimensions
Height 25.00mm
Length 50.00mm
Width 32.00mm
Compliance
RoHS Status ROHS3 Compliant
