B65877B0000R087
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
EPCOS B65877B0000R087Transformer Cores, PQ, PQ26/20, N87, 44.4 mm, 122.3 mm
PDF
/
Buying Options
Total Price: USD $4.44
Unit Price: USD $4.4352
≥1 USD $4.4352
≥10 USD $3.7796
≥100 USD $2.876192
≥500 USD $2.794
≥1000 USD $2.465232
≥3000 USD $2.300874
Inventory: 550
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Supplier Device Package PQ 26 x 20
Material N87
Technical
Series B65877B
Tolerance -20% +30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type PQ
Gap Ungapped
Effective Area (Ae) mm2 122.3
Effective Length (le) mm 44.4
Effective Magnetic Volume (Ve) mm3 5435
Core Factor (ΣI/A) mm1 0.363
Initial Permeability (μi) 2200
Minimum Core Cross Section (Amin) mm2 108.8
Inductance Factor (Al) 5μH
Effective Permeability (μe) 1440
Dimensions
Height 10.08mm
Length 26.50mm
Width 19.00mm
Compliance
RoHS Status ROHS3 Compliant
