B65875A0000R097
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories PQ20/20 N97
PDF
/
Buying Options
Total Price: USD $3.17
Unit Price: USD $3.168
≥1 USD $3.168
≥10 USD $2.71744
≥100 USD $2.03808
≥500 USD $1.981408
≥1000 USD $1.641754
≥3000 USD $1.57256
Inventory: 435
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 14.00mm
Length 20.50mm
Height 10.10mm
Technical
Effective Permeability (μe) 1565
Inductance Factor (Al) 2.75μH
Minimum Core Cross Section (Amin) mm2 54.4
Initial Permeability (μi) 2300
Core Factor (ΣI/A) mm1 0.718
Effective Magnetic Volume (Ve) mm3 2843
Effective Length (le) mm 45.2
Effective Area (Ae) mm2 62.9
Gap Ungapped
Core Type PQ
Finish Uncoated
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance -20% +30%
Series B65875A
Published 2010
Physical
Material N97
Supplier Device Package PQ 20 x 20
Supply Chain
Factory Lead Time 24 Weeks
