B65845J0000Y038

TDK Electronics Inc.
RoHS
RoHS RoHS compliant
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description Ferrite Cores & Accessories EP17-T38 '+40%-30%
PDF
/
Inventory: 5355
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 24 Weeks

Physical

Supplier Device Package EP 17
Material T38

Technical

Series B65845
Tolerance -30% +40%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type EP
Gap Ungapped
Effective Area (Ae) mm2 33.9
Effective Length (le) mm 28.5
Effective Magnetic Volume (Ve) mm3 966
Core Factor (ΣI/A) mm1 0.84
Initial Permeability (μi) 10000
Minimum Core Cross Section (Amin) mm2 25.5
Inductance Factor (Al) 10.8μH
Effective Permeability (μe) 7220

Dimensions

Height 8.50mm
Length 18.40mm
Width 11.25mm

Compliance

RoHS Status ROHS3 Compliant
