B65843A0000Y066
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories EP13-T66 +40%-30%
PDF
/
Inventory: 7015
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Inside 4.5 mm
Width 9.00mm
Length 12.80mm
Height 6.50mm
Technical
Effective Permeability (μe) 8400
Inductance Factor (Al) 8.5μH
Minimum Core Cross Section (Amin) mm2 14.9
Initial Permeability (μi) 13000
Core Factor (ΣI/A) mm1 1.24
Effective Magnetic Volume (Ve) mm3 472
Effective Length (le) mm 24.2
Effective Area (Ae) mm2 19.5
Gap Ungapped
Core Type EP
Finish Uncoated
Outside Diameter 9.7 mm
Inductance 8.5 μH
Depth 13mm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance -30% +40%
Series B65843A
Physical
Weight 4.500005g
Material T66
Supplier Device Package EP 13
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 24 Weeks
