B65839A0000R030
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories EP7-N30 +30%-20%
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
≥10 USD $0.83512
≥100 USD $0.618816
≥500 USD $0.58784
≥1000 USD $0.525888
≥3000 USD $0.494982
Inventory: 1898
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Supplier Device Package EP 7
Material N30
Technical
Series B65839
Tolerance -20% +30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type EP
Gap Ungapped
Effective Area (Ae) mm2 10.3
Effective Length (le) mm 15.7
Effective Magnetic Volume (Ve) mm3 162
Core Factor (ΣI/A) mm1 1.52
Initial Permeability (μi) 4300
Minimum Core Cross Section (Amin) mm2 8.5
Inductance Factor (Al) 2μH
Effective Permeability (μe) 2430
Dimensions
Height 3.75mm
Length 9.40mm
Width 6.50mm
Compliance
RoHS Status ROHS3 Compliant
