B65819N0400A048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite RM7 Core (11.3x17.2mm) N48 AL=400nH 3%
PDF
/
Inventory: 9799
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 20.30mm
Height 6.75mm
Technical
Initial Permeability (μi) 2300
Core Factor (ΣI/A) mm1 0.75
Effective Magnetic Volume (Ve) mm3 1190
Effective Length (le) mm 29.8
Effective Area (Ae) mm2 40
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 3%
Physical
Material N48
Supplier Device Package RM 7
Supply Chain
Factory Lead Time 24 Weeks
