B65813J0160A041
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite RM10 Core (13.5x24.7mm) N41 AL=160nH 3%
PDF
/
Inventory: 6413
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Supplier Device Package RM 10
Material N41
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type RM
Effective Area (Ae) mm2 98
Effective Length (le) mm 44
Effective Magnetic Volume (Ve) mm3 4310
Core Factor (ΣI/A) mm1 0.45
Initial Permeability (μi) 2800
Minimum Core Cross Section (Amin) mm2 90
Dimensions
Height 9.35mm
Length 28.50mm
Width 13.50mm
Compliance
RoHS Status ROHS3 Compliant
