B65811J0160A087
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite RM8 Core (11x19.7mm) N87 AL=160nH 3%
PDF
/
Inventory: 970
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 11.00mm
Length 23.20mm
Height 8.25mm
Technical
Minimum Core Cross Section (Amin) mm2 55
Core Factor (ΣI/A) mm1 0.59
Effective Magnetic Volume (Ve) mm3 2430
Effective Length (le) mm 38
Effective Area (Ae) mm2 64
Gap Gapped
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series B65811
Physical
Material N87
Supplier Device Package RM 8
Supply Chain
Factory Lead Time 24 Weeks
