B65811F0630J048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Core RM Core 23.2mm 16.5mm Transformer Applications
PDF
/
Buying Options
Total Price: USD $4.14
Unit Price: USD $4.136
≥1 USD $4.136
≥10 USD $3.52352
≥100 USD $2.697024
Inventory: 1431
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 11.00mm
Length 23.20mm
Height 8.25mm
Technical
Effective Permeability (μe) 338
Inductance Factor (Al) 630nH
Core Factor (ΣI/A) mm1 0.68
Effective Magnetic Volume (Ve) mm3 1825
Effective Length (le) mm 35.1
Effective Area (Ae) mm2 52
Gap Gapped
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Series B65811
Physical
Material N48
Supplier Device Package RM 8
Supply Chain
Factory Lead Time 24 Weeks
