B65807J0400J087
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite RM6 Core (8.2x14.7mm) N87 AL=400nH 5%
PDF
/
Buying Options
Total Price: USD $2.25
Unit Price: USD $2.2528
≥1 USD $2.2528
≥10 USD $1.92984
≥100 USD $1.447424
≥500 USD $1.40712
≥1000 USD $1.246344
≥3000 USD $1.165965
Inventory: 1924
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 8.20mm
Length 17.90mm
Height 6.25mm
Technical
Minimum Core Cross Section (Amin) mm2 31
Initial Permeability (μi) 2200
Core Factor (ΣI/A) mm1 0.78
Effective Magnetic Volume (Ve) mm3 1050
Effective Length (le) mm 28.6
Effective Area (Ae) mm2 36.6
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 5%
Physical
Material N87
Supplier Device Package RM 6
Supply Chain
Factory Lead Time 24 Weeks
