B65805P0000R092
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite RM5 Core (6.8x12.3mm) N92 AL=1900nH 30% -20% Ungapped
PDF
/
Inventory: 2150
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6.80mm
Length 14.60mm
Height 3.90mm
Technical
Effective Permeability (μe) 1080
Inductance Factor (Al) 1.9μH
Minimum Core Cross Section (Amin) mm2 18
Initial Permeability (μi) 1500
Core Factor (ΣI/A) mm1 0.71
Effective Magnetic Volume (Ve) mm3 430
Effective Length (le) mm 17.5
Effective Area (Ae) mm2 24.5
Gap Ungapped
Core Type RM
Finish Uncoated
Depth 7.8mm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance -20% +30%
Series B65805P
Physical
Material N92
Supplier Device Package RM 5 LP
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
Factory Lead Time 27 Weeks
