B65805J0000R030
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite RM5 Core (6.8x12.3mm) N30 AL=3500nH 30% -20% Ungapped
PDF
/
Buying Options
Total Price: USD $1.76
Unit Price: USD $1.76
≥1 USD $1.76
≥10 USD $1.51536
≥100 USD $1.151744
≥500 USD $1.0912
≥1000 USD $0.969936
≥3000 USD $0.909286
Inventory: 2094
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6.80mm
Length 14.60mm
Height 5.25mm
Technical
Effective Permeability (μe) 2590
Inductance Factor (Al) 3.5μH
Minimum Core Cross Section (Amin) mm2 18
Initial Permeability (μi) 4300
Core Factor (ΣI/A) mm1 0.93
Effective Magnetic Volume (Ve) mm3 526
Effective Length (le) mm 22.1
Effective Area (Ae) mm2 23.8
Gap Ungapped
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance -20% +30%
Series B65805
Physical
Material N30
Supplier Device Package RM 5
Supply Chain
Factory Lead Time 27 Weeks
