B65713A2500J027
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories PM 87X70 N272500 +5%-5%
PDF
/
Inventory: 5559
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Inductance 250 nH
Finish Uncoated
Core Type PM
Effective Area (Ae) mm2 910
Effective Length (le) mm 146
Effective Magnetic Volume (Ve) mm3 133000
Core Factor (ΣI/A) mm1 0.16
Initial Permeability (μi) 2000
Minimum Core Cross Section (Amin) mm2 700
Tolerance 5%
Dimensions
Diameter 87.00mm
Height 35.00mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Material N27
Supplier Device Package PM 87 x 70
Supply Chain
Factory Lead Time 24 Weeks
