B65701W0000R030
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories P 30X19 N30 11500 +30%-20%
PDF
/
Buying Options
Total Price: USD $4.9
Unit Price: USD $4.9016
≥1 USD $4.9016
≥10 USD $4.17472
≥100 USD $3.195808
Inventory: 739
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 51 Weeks
Physical
Supplier Device Package P 30 x 19
Material N30
Technical
Published 2013
Series B65701
Tolerance -20% +30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type P (Pot Core)
Gap Ungapped
Effective Area (Ae) mm2 145
Effective Length (le) mm 46
Effective Magnetic Volume (Ve) mm3 6670
Core Factor (ΣI/A) mm1 0.32
Initial Permeability (μi) 4300
Minimum Core Cross Section (Amin) mm2 117
Inductance Factor (Al) 11.5μH
Effective Permeability (μe) 2900
Dimensions
Diameter 30.50mm
Height 9.50mm
Compliance
RoHS Status ROHS3 Compliant
