B65701T0400A048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories P 30X19 N48 400 +3% -3%
PDF
/
Buying Options
Total Price: USD $9.75
Unit Price: USD $9.7504
≥1 USD $9.7504
≥10 USD $8.30456
≥100 USD $6.318752
≥500 USD $6.138176
≥1000 USD $5.416074
≥3000 USD $5.055019
Inventory: 680
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Supplier Device Package P 30 x 19
Material N48
Technical
Packaging Bulk
Series B65701
Tolerance ±3%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Depth 19mm
Inductance 400 nH
Finish Uncoated
Core Type P (Pot Core)
Gap Gapped
Effective Area (Ae) mm2 136
Effective Length (le) mm 45
Effective Magnetic Volume (Ve) mm3 6120
Core Factor (ΣI/A) mm1 0.33
Effective Permeability (μe) 105
Dimensions
Diameter 30.50mm
Height 9.50mm
Compliance
RoHS Status ROHS3 Compliant
