B65691K0100A048
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Core P Core 35.6mm 59.3mm General Application
PDF
/
Inventory: 3246
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Inside 5.5 mm
Technical
Effective Permeability (μe) 14
Minimum Core Cross Section (Amin) mm2 445
Core Factor (ΣI/A) mm1 0.181
Effective Magnetic Volume (Ve) mm3 42680
Effective Length (le) mm 88
Effective Area (Ae) mm2 485
Gap Ungapped
Core Type P (Pot Core)
Finish Uncoated
Outside Diameter 59.3 mm
Inductance 100 nH
Depth 35.6mm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±3%
Series B65691
Published 2013
Packaging Bulk
Physical
Material N48
Package / Case 100
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 24 Weeks
